This security bundle combines a robust high-security notebook with a high-performance bi-spectral camera, a portable thermal imaging device, and three modular sensors equipped with interchangeable lenses and different focal lengths. The combination of these components enables complete mobile surveillance, even in challenging environments and extreme weather conditions. With VPN-protected 5G connectivity and intelligent video analytics, this system delivers real-time monitoring, rapid response times, and reliable documentation of security-relevant events. Thanks to flexible daily rental, this bundle is particularly well-suited for temporary deployments, mobile security operations, or crisis interventions at changing locations.
Included Components and Technical Specifications
Robust High-Security Notebook
The notebook is the heart of the system and has been specifically designed for use in extreme environments.
Technical Highlights:
- Pre-installed Video Management System (Server & Client): Fully configured VMS software for recording and monitoring, ready for immediate use.
- Secure 5G Connectivity: Integrated 5G modem with VPN protection for encrypted real-time data transmission.
-
Powerful Hardware:
- Processor: Intel® Ultra 5 135H
- Memory: 32 GB DDR4 RAM (expandable)
- Storage: 512 GB NVMe OPAL-SSD (hardware-encrypted)
- Extremely Rugged (IP66): Dust and water resistant, shockproof according to MIL-STD-810H.
-
Long Runtime:
- Hot-swappable batteries (up to 36 hours of continuous operation)
- Optional fuel cell module for autonomous long-term operations.
Mobile Bi-Spectral Camera
This camera combines high-resolution color imaging with thermal imaging, enabling 24/7 surveillance even in fog, smoke, or complete darkness.
Technical Highlights:
-
Dual-Sensor System:
- Optical Sensor: 4 MP (2,560 × 1,440 px), 25x optical zoom
- Thermal Sensor: 640 × 512 px, NETD < 35 mK
- Real-Time Transmission: 5G & Wi-Fi streaming for live data transmission and remote control.
- GPS Tracking: Location and movement tracking for complete situational awareness.
-
Intelligent Video Analytics:
- Motion detection & auto-tracking
- Early fire detection & temperature monitoring
- Flexible Mounting: Magnetic high-suction mount for quick installation on vehicles or masts.
Portable Thermal Imaging Device
A compact handheld device for mobile thermal imaging, specifically designed for detecting people and vehicles both day and night.
Technical Highlights:
- High-Resolution Thermal Sensor (640 × 512 px): For precise temperature display.
- High Range: 35 mm lens, detecting people at distances up to 1.8 km.
- Wide Field of View: Wide-angle optics for comprehensive area surveillance.
- Rugged Design: Shockproof, weather-resistant, designed for harsh operating conditions.
- Day & Night Operation: Independent of light sources, ideal for covert operations.
Three Modular Thermal Sensors
The bundle includes three high-resolution infrared sensors, which can be equipped with different lenses and focal lengths. This allows optimal adaptation to the specific application and provides greater range as well as enhanced detail resolution.
Technical Highlights:
-
Resolution & Sensor Type:
- High-resolution 640 × 512 pixel infrared detector with uncooled VOx microbolometer technology.
- NETD < 35 mK (at 25 °C, F/1.0) for highly precise temperature measurements, even with minimal temperature differences.
-
Flexible Optics:
- Supports interchangeable lenses with various focal lengths (e.g., 15 mm, 25 mm, 50 mm, 75 mm, 100 mm).
- Motorized zoom options available (e.g., 20–100 mm or 30–150 mm) for dynamic adjustments.
-
Extended Detection Ranges:
- Person Detection: Up to 1,458 m (depending on optics and environment).
- Vehicle Detection: Up to 4,472 m – extendable to over 10 km with telephoto lenses.
-
Connectivity & Interfaces:
- Ethernet network port, ONVIF & RTSP protocols for integration into surveillance systems.
- RS-485 & RS-232 control ports, compatible with PTZ controls.
- MicroSD storage option for local data backup.
-
Environmental Durability & Power Supply:
- Operating temperature range of -40 °C to +70 °C for extreme deployments.
- Low power consumption (<2.4 W) for long-term, autonomous operation.
- Optional battery/accupack usage for off-grid operations.
- Protection class up to IP66/IP67 in suitable enclosures for dust and water resistance.
Ideal for Authorities, Security Services, Personal Protection & Property Protection
This bundle has been specifically developed for professional security applications and is suitable for:
- Police & Special Forces: Mobile situational awareness & tactical surveillance during operations.
- Fire Services & Disaster Response: Early detection of fires & temperature monitoring.
- Personal Protection: Discreet yet highly precise monitoring of danger zones for VIP protection.
- Property Protection & Facility Security: Seamless control over sensitive areas.
Rent Flexibly Now – Maximum Security Exactly When You Need It
- Daily Rental: No long-term commitment
- Ready for Immediate Use & Pre-configured
- Maximum Flexibility for Temporary Deployments
📞 Contact us for your individual rental offer!
